MIL-DTL-3928/18D
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
.58 (BC)
.52 (BC)
14.7 (BC)
13.2 (BC)
J
1.380
1.370
35.05
34.80
B
.21
.15
5.3
3.8
K
.697
.677
17.70
17.20
C
.10
---
2.5
---
L
.154 dia
.139 dia
3.91dia
3.53 dia
D
1.55
---
39.4
---
M
1.78
1.72
45.2
43.7
E
.34
.28
8.6
7.1
N
.885
.865
22.48
21.97
F
.28
.22
7.1
5.6
P
1.072 dia
1.052 dia
27.23 dia 26.72 dia
G
.130
.120
3.30
3.05
Q
2.33 dia
2.27 dia
59.2 dia
57.7 dia
H
1.560
1.556
39.62
39.52
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
4. Round corners of case may be squared.
FIGURE 2. Switch configuration and schematic, PINs M3928/18-02 and M3928/18-08.
3
