MIL-DTL-3928/18D
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
.154
.139
3.91
3.53
H
.135
.115
3.43
2.92
B
1.78
1.72
45.2
43.7
J
.28
.22
7.1
5.6
C
.885
.865
22.48
21.97
K
.31
---
7.9
---
D
2.34 dia
2.28 dia
59.4 dia
57.9 dia
L
1.385
1.365
35.18
34.67
E
1.568 dia
1.548 dia
39.83 dia 39.32 dia
M
.697
.677
17.70
17.20
F
.28
.22
7.1
5.6
N
1.072 dia
1.052 dia
27.23 dia
26.72 dia
G
2.00
---
50.8
---
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
FIGURE 7. Switch configuration and schematic, PIN M3928/18-07.
8
