MIL-DTL-3928/18D
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
1.77
1.73
45.0
43.9
G
1.85
---
47.0
---
B
1.65
---
41.9
---
H
.38
---
9.7
---
C
2.33
2.29
59.2
58.2
J
.130
.120
3.30
3.05
D
.135
.120 dia
3.43 dia
3.05 dia
K
1.380
1.370
35.05
34.80
E
1.52 dia
1.48 dia
38.6 dia
37.6 dia
L
.885 dia
.875 dia
22.48 dia
22.23 dia
F
.27
.23
6.9
5.8
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .005 (± 0.13 mm) for three place decimals and
± .02 (±0.5 mm) for two place decimals.
FIGURE 4. Switch configuration and schematic, PIN M3928/18-04.
