MIL-DTL-3928/18D
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
1.77
1.73
45.0
43.9
F
1.85
---
47.0
---
B
2.33 dia
2.29 dia
59.2 dia
58.2 dia
G
.27
---
6.9
---
C
.135 dia
.120 dia
3.43 dia
3.05 dia
H
.130
.120
3.30
3.05
D
.152 dia
.148 dia
3.86 dia
3.76 dia
J
1.380
1.370
35.05
34.80
E
.95
---
24.1
---
K
.885
.875
22.48
22.23
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .005 (± 0.13 mm) for three place decimals and
± .02 (±0.5 mm) for two place decimals.
FIGURE 5. Switch configuration and schematic, PIN M3928/18-05.
6
