MIL-DTL-3928/15G
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
2.78
-----
70.61
---
F
.890
.870
22.606
22.098
B
2.40
-----
60.96
---
G
.41
.35
10.41
8.89
C
1.02
-----
25.91
---
H
.63
----
16.00
-----
D
2.51
-----
63.75
J
.181 dia
----
4.597 dia  -----
E
2.510
-----
63.754
FIGURE 12. Switch configuration and schematic, PIN M3928/15-17.
24
