MIL-DTL-3928/15G
Dimensions
Inches
Millimeters
Inches
Millimeters
Lette
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
.230
.210
5.84
5.33
H
1.2
---
30
---
B
.450
.430
11.43
10.92
J
.103
.083
2.62
2.11
C
.890
.870
22.61
22.10
K
.35
---
8.9
---
D
1.5
---
38
---
L
.160
.140
4.06
3.56
E
.35
---
8.9
---
M
.570
---
14.5
---
F
.23
.17
5.8
4.3
N
.126 dia
.106 dia
3.20 dia
2.69 dia
G
.56
---
14.2
---
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (± 0.8 mm) for two place decimals.
4. Round corners of case may be squared.
FIGURE 1A. Alternate construction for PINs M3928/15-01, M3928/15-02, and M3928/15-12.
3
