MIL-DTL-3928/15G
POSITION 1. Energize terminal 1. JC connects to J1, J2 is open circuit.
POSITION 2. Energize terminal 2. JC connects to J2, J1 is open circuit.
SCHEMATIC (shown in position 1)
Dimensions
Inches
Millimeters
Inches
Millimeters
Lette
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
1.15
1.09
29.2
27.7
K
.680
.660
17.27
16.76
B
.28
.22
7.1
5.6
L
.450
.430
11.43
10.92
C
.28
.22
7.1
5.6
M
.890
.870
22.6 1
22.10
D
.35
---
8.9
---
N
1.37
1.31
34.8
33.3
E
1.50
---
38.1
---
P
.19
.13
4.8
3.3
F
.31
---
7.9
---
Q
.20
.14
5.1
3.6
G
.130 dia
.110 dia
3.30 dia
2.79 dia
R
.28
.22
7.1
5.6
H
.230
.210
5.84
5.33
S
.53
.47
13.5
11.9
J
.450
.430
11.43
10.92
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
4. Round corners of case may be squared.
FIGURE 5. Switch configuration and schematic, PIN M3928/15-08 - Continued.
