MIL-DTL-3928/15G
Shown in failsafe position (Position 1).
Energize to connect COM to NO (Position 2).
SCHEMATIC
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
.23
.17
5.8
4.3
J
.230
.210
5.84
5.33
B
.22
.16
5.6
4.1
K
.450
.430
11.43
10.92
C
.66
.60
16.8
15.2
L
.680
.660
17.27
16.76
D
1.38
1.32
35.1
33.5
M
.450
.430
11.43
10.92
E
.19
.13
4.8
3.3
N
.890
.870
22.61
22.10
F
.103
.083
2.62
2.11
P
1.37
1.31
34.8
33.3
G
.50
---
12.7
---
Q
.28
.22
7.1
5.6
H
.130 dia
.110 dia
3.30 dia
2.79 dia
R
.53
.47
13.5
11.9
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (± 0.8 mm) for two place decimals.
4. Round corners of case may be squared.
FIGURE 6. Switch configuration and schematic, PIN M3928/15-09 - Continued.
14
