INCH-POUND
MIL-DTL-55041F
5 January 2012
SUPERSEDING
MIL-DTL-55041E
15 August 2007
DETAIL SPECIFICATION
SWITCHES, WAVEGUIDE,
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the general requirements for waveguide switches, either manually or
electromechanically operated, designed to connect and disconnect one or more waveguide sections to other
waveguide sections. Detail requirements and specific characteristics of switches are be specified in the applicable
specification sheet.
1.2 Part or Identifying number (PIN). The military PIN consists of the letter "M", the basic number of the
specification sheet, an assigned dash number (see 3.1), and the letter N or S; where N indicates a non-screened item
and S indicates a screened item.
EXAMPLE:
M55041/3-
01
N
or
S
Military designator and
Dash number
Non-screened
Screened
specification sheet number
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract (see 6.2).
FEDERAL STANDARDS
FED STD H28
-
Screw Thread Standards for Federal Services.
FED-STD-595/27038
-
Colors Used in Government Procurement.
Comments, suggestions or questions on this document should be addressed to DLA Land and Maritime, ATTN:
VAT, Post Office Box 3990, Columbus, OH 43218-3990, or emailed to TubesAmps@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST Online
database at https://assist.daps.dla.mil
AMSC N/A
FSC 5985
