MIL-DTL-55041F
FIGURE 1. Run-in and cycle life test setup.
FIGURE 2. Operating and holding current test setup.
4.7.8 Rotor motion delay (see 3.10). With the switch at room ambient temperature, apply nominal operating
voltage (see 3.1) and measure the rotor motion delay in both the energized and deenergized position using the test
setup of figure 3. Repeat the rotor motion delay measurement for each electrically selected position of the switch.
